SLV White Series Front Panel Board – 5002 / 7002 Volume & LED PCB

The SLV 3U-LED-V1.0 is a professional-grade interface module designed for the larger 3U chassis of the White Series flagship amplifiers. This board is the central hub for monitoring the health and performance of the 5002 and 7002 units. It combines high-precision analog gain control with a multi-segment LED monitoring system, ensuring the operator has full control and visibility over the amplifier’s status during high-demand performance.

Key Features & Build Quality

• High-Precision Potentiometers: Equipped with dual heavy-duty volume controllers for independent and accurate gain staging of Channel A and Channel B.

• 8-Segment Diagnostic Array: Each channel features a dedicated vertical LED ladder providing critical real-time data:

  • Power/Ready: Confirms the channel is active and protection relays are engaged.

  • Signal Detection: Visual confirmation of incoming audio.

  • Multi-Level Metering: Clear increments for signal strength monitoring.

  • Clip/Limit: Immediate warning of signal peak or distortion.

  • Protect/Thermal: Indicators for DC offset, short circuit, or overheating status.

• Optimized for 3U Chassis: The PCB layout is specifically sized for the larger faceplates of the 5002 and 7002 models, ensuring perfect alignment with factory windows.

• Industrial Connectivity: Features 10-pin and 3-pin white header connectors for secure, noise-free communication with the main input and power stages.

• Low-Noise Design: High-quality ground plane and component selection prevent "zipper noise" or interference when adjusting volume levels.

Technical Specifications

• Model Compatibility: SLV White Series 5002 and 7002.

• PCB Revision: 3U-LED-V1.0.

• Chassis Requirement: 3U Rackmount Height.

• Monitoring: Independent LED ladders for CHA and CHB.

• Components: Long-life potentiometers and high-brightness industrial LEDs.

Applications

• Flagship Restoration: The direct replacement part for fixing non-responsive LEDs or "scratchy" volume controls in 5002 and 7002 amplifiers.

• Pro Audio Servicing: A vital spare part for stadium and touring audio technicians to ensure visual monitoring is accurate.

• System Upgrades: Provides a fresh, reliable interface for well-used professional rack equipment.

Installation Note: When mounting this board to the front panel, ensure the LED spacers are seated correctly to prevent light bleed between indicators. Double-check the ribbon cable orientation on the header pins to ensure the protection and clip warnings sync correctly with the main power modules.
